GE
Data Sheet
May 2, 2013
©2013 General Electric Company. All rights reserved.
Page 1
CAR0812FP series rectifier
Input: 85V
AC
to 264V
AC
; Output: 12V
DC
@ 850W; 3.3V
DC
or 5 V
DC
@ 1A
Features
Universal input with PFC
Constant power characteristic
2 front panel LEDs: LED1-input
LED2 - [output, fault, over temp]
Remote ON/OFF control of the 12V
DC
output
Remote sense on the 12V
DC
output
No minimum load requirements
Active load sharing (single wire)
Hot Plug-ability
Efficiency: typically 92.5% @ 50% load
and 90.0% @ 20% load
Standby orderable either as 3.3V
DC
or 5V
DC
Auto recoverable OC & OT protection
Operating temperature: -10 - 70C (de-rated above 50C)
Digital status & control: I
2
C and PMBus serial bus
EN/IEC/UL60950-1 2
nd
edition; UL, CSA and VDE
EMI: class A or B FCC docket 20780 part 15, EN55022
Meets EN6100 immunity and transient standards
Shock & vibration: NEBS GR-63-CORE, level 3
Applications
12V
DC
distributed power architectures
Datacom and Telecom applications
Mid to high-end Servers
Enterprise Networking
Network Attached Storage
Telecom Access Nodes
Routers/Switches
ATE Equipment
Description
The CAR0812FP series of rectifiers provide highly efficient isolated power from world-wide commercial AC mains.
Offered in the industry standard compact 1U form factor, these rectifiers complement the CAR0812DC converter line,
providing comprehensive solutions for systems connected either to commercial ac mains or 48/60V
DC
power plants.
This plug and play approach, between AC and DC input units, has significant advantages since systems can be readily
reconfigured by simply replacing the power supply.
The high-density, front-to-back airflow is designed for minimal space utilization and is highly expandable for future
growthThe industry standard PMBus compliant I
2
C communications buss offers a full range of control and monitoring
capabilities. The SMBAlert signal pin alerts customers automatically of any state change within the power supply.
*
UL is a registered trademark of Underwriters Laboratories, Inc.
†
CSA is a registered trademark of Canadian Standards Association.
‡
VDE is a trademark of Verband Deutscher Elektrotechniker e.V.
§
Intended for integration into end-user equipment. All the required procedures for CE marking of end-user equipment should be followed. (The CE mark is placed on selected products.)
** ISO is a registered trademark of the International Organization of Standards.
+ PMBus name and logo are registered trademarks of the System Management Interface Forum (SMIF)
RoHS Compliant
