5-55 Terminal 33 Low Frequency

Range:

Function:

20 Hz

[20 - 4999 Hz]

Enter low frequency corresponding to low motor shaft speed (i.e. low reference value) in par. 5-57.

5-56 Terminal 33 High Frequency

Range:

Function:

5000 Hz

[21 - 5000 Hz]

Enter high frequency corresponding to high motor shaft speed (i.e. high reference value) in par. 5-58.

5-57 Terminal 33 Low Ref./Feedb. Value

Range:

Function:

0.000

[-4999 - 4999]

Set reference/feedback value corresponding to low pulse frequency value set in par. 5-55.

5-58 Terminal 33 High Ref./Feedb. Value

Range:

Function:

50.000

[-4999 - 4999]

Set reference/feedback value corresponding to high pulse frequency value set in par. 5-56.
