GE
Data Sheet
CAR1212DC series DC-DC converter
Input: -36V
D C
to -75V
DC
; Output: 12V
DC
@ 1200W; 3.3V
DC
or 5 V
DC
@ 1A
October 21, 2013 ©2013 General Electric Company. All rights reserved. Page 2
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are absolute stress ratings only, functional
operation of the device is not implied at these or any other conditions in excess of those given in the operations sections of the data sheet.
Exposure to absolute maximum ratings for extended periods can adversely affect the device reliability.
Parameter Symbol Min Max Unit
Input Voltage: Continuous V
IN
0 75 V
DC
Operating Ambient Temperature T
A
-10 70 1 °C
Storage Temperature Tstg -40 85 °C
I/O Isolation voltage (100% factory Hi-Pot tested) 1500 V
DC
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, load, and temperature conditions.
INPUT
Parameter Symbol Min Typ Max Unit
Operational Range
V
IN
-36 -48/60 -75
V
DC
12V
DC
output turned OFF -35
12V
DC
output turned ON -36
Idling Power 12V
DC
output OFF
W
35
W
12V
DC
output ON 45
Maximum Input Current V
IN
= -36V
DC
I
IN
38 A
DC
(V
OUT
= V
O, set
, I
OUT
=I
O, max
)
Cold Start Inrush Current
I
IN
40 A
PEAK
(Excluding x-caps, 25°C, <10ms, per ETSI 300-132)
Efficiency
η 90 %
(T
amb
=25°C, V
IN
= -48V
DC
, V
OUT
= 12V
DC
, 60-80% load)
Holdup time (V
IN
= -48V
DC
, V
OUT
≥ 10.8Vdc, T
AMB
25°C, I
OUT
=I
O, max
) T 2.5 ms
Isolation Input/Output 1500 V
DC
Input/Frame 1500 V
DC
Output/Frame 100 V
DC
12V
DC
MAIN OUTPUT
Parameter Symbol Min Typ Max Unit
Output power P
OUT
0 1200 W
Set point @ 50% load
V
OUT
11.9 12.00 12.1 V
DC
Overall regulation (load, temperature) -2 +2 %
Remote sense sum of hot & return 0.25 V
DC
Ripple and noise 2 120 mV
p-p
1 Derated above 50°C at 2.5%/°C
2 Measured across a 10µf tantalum and a 0.1µf ceramic capacitors in parallel. 20MHz bandwidth
