Data Sheet
CAR1212DC series DC-DC converter
Input: -36V
D C
to -75V
DC
; Output: 12V
DC
@ 1200W; 3.3V
DC
or 5 V
DC
@ 1A
October 21, 2013 ©2013 General Electric Company. All rights reserved. Page 14
Alarm Table
Test Condition
LED Indicator Monitoring Signals
INPUT OK DC OK FAULT FAULT DC OK INPUT OK TEMP OK
1 Normal Operation Green Green OFF High High High High
2 Low or NO INPUT OFF OFF RED Low Low Low High
3 OVP Green OFF RED Low Low High High
4 Over Current Green OFF RED Low Low High High
5 Over Temp Fault Green OFF RED Low Low High Low
Note: Test condition #2 has 2 modules working in parallel. One module is running and the other has no input.
