Data Sheet
September 10, 2013 Austin Lynx TM 24V: Non-isolated Power Modules:
18/20– 30/32Vdc input; 3 – 6Vdc & 5 – 15Vdc Output; 30/50W
LINEAGE POWER 5
Feature Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature
conditions. See Feature Descriptions for additional information.
Parameter Device Symbol Min Typ Max Unit
On/Off Signal interface
(On/Off is open collector/drain logic input;
Signal referenced to GND - See feature description
section)
Device is with suffix “4” – Positive Logic
Logic High (On/Off pin open – Module ON)
Input High Current All I IH ⎯ 10 µA
Input High Voltage All V IH V
IN
−2.5V ⎯ 30 V
Logic Low (Module OFF)
Input Low Current All I IL ⎯ ⎯ 1 mA
Input Low Voltage All V IL -0.3 ⎯ 1.2 V
Turn-On Delay and Rise Times
(V
IN
=V
IN, nom
, I
O
=I
O, max ,
V
O
to within ±1% of steady state)
Case 1: On/Off input is enabled and then
input power is applied (delay from instant at
which V
IN
= V
IN, min
until V o = 10% of V o, set )
All Tdelay 2 4 8 msec
Case 2: Input power is applied for at least one second
and then the On/Off input is enabled (delay from instant
at which Von/Off is enabled until V
o = 10% of V o, set )
All Tdelay 2 4 8 msec
Output voltage Rise time (time for V o to rise from
10% of Vo, set to 90% of Vo, set)
All Trise 2 5 9 msec
Output voltage overshoot 3.0 % V
O, set
I
O
= I
O, max
; V
IN, min
– V
IN, max
, T
A
= 25 o C
Remote Sense Range ― ― 0.5 V
Over temperature Protection All T
ref
⎯ 125 135 °C
(See Thermal Consideration section)
Input Undervoltage Lockout
Turn-on Threshold AXB030 17 Vdc
AXB050 19 Vdc
Turn-off Threshold AXB030 15 Vdc
AXB050 17 Vdc
