Data Sheet
September 10, 2013 Austin Lynx TM 24V: Non-isolated Power Modules:
18/20– 30/32Vdc input; 3 – 6Vdc & 5 – 15Vdc Output; 30/50W
LINEAGE POWER 19
Document No: DS05-032 ver.1.24
PDF name: lynx_24v_ds.pdf
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 1. Device Codes
Device Code
Input
Voltage Range
Output
Voltage
Output
Power
On/Off
Logic
Connector
Type
Comcodes
AXB030X43-SR 18 – 30Vdc 3.0 – 6.0Vdc 30W Positive SMT 108992673
AXB030X43-SRZ 18 – 30Vdc 3.0 – 6.0Vdc 30W Positive SMT CC109106738
AXB050X43-SR 20 – 32Vdc 5.0 – 15.0Vdc 50W Positive SMT 108992681
AXB050X43-SRZ 20 – 32Vdc 5.0 – 15.0Vdc 50W Positive SMT CC109104857
-Z refers to RoHS-compliant codes
