Data Sheet
September 10, 2013 Austin Lynx TM 24V: Non-isolated Power Modules:
18/20– 30/32Vdc input; 3 – 6Vdc & 5 – 15Vdc Output; 30/50W
LINEAGE POWER 4
Electrical Specifications (continued)
Parameter Device Symbol Min Typ Max Unit
Dynamic Load Response
(dI
O
/dt=5A/ μs; V
IN
=V
IN
,
nom
T
A
=25°C)
Load Change from Io= 50% to 100% of I
O
,max; No
external output capacitors
Peak Deviation (Vo = 3.3Vdc) AXB030 V
pk
300 mV
Peak Deviation (Vo = 12Vdc) AXB050 V
pk
220 mV
Settling Time (V
O
<10% peak deviation) All t
s
50 μs
(dI
O
/dt=5A/ μs; V
IN
=V
IN
,
nom
; T
A
=25°C)
Load Change from I
O
= 100% to 50%of I
O
,
max
: No
external output capacitors
Peak Deviation (Vo = 3.3Vdc) AXB030 V
pk
320 mV
Peak Deviation (Vo = 12Vdc) AXB050 V
pk
220 mV
Settling Time (V
O
<10% peak deviation) All t
s
50 μs
(dI
O
/dt=5A/ μs; V
IN
=V
IN
,
nom
; T
A
=25°C)
Load Change from Io= 50% to 100% of Io,max;
2x150 μF polymer capacitor
Peak Deviation (Vo = 3.3Vdc) AXB030 V
pk
⎯ 120 mV
Peak Deviation (Vo = 12Vdc) AXB050 V
pk
⎯ 130 mV
Settling Time (V
O
<10% peak deviation) All t
s
⎯ 50 μs
(dI
O
/dt=5A/ μs; V
IN
=V
IN
,
nom
; T
A
=25°C)
Load Change from Io= 100% to 50%of I
O,max
:
2x150 μF polymer capacitor
Peak Deviation (Vo = 3.3Vdc) AXB030 V
pk
⎯ 130 mV
Peak Deviation (Vo = 12Vdc) AXB050 V
pk
130 mV
Settling Time (V
O
<10% peak deviation) All t
s
⎯ 50 ⎯ μs
General Specifications
Parameter Device Min Typ Max Unit
Calculated MTBF (V
IN
= V
IN, nom
, I
O
= 0.8I
O, max
,
T
A
=40°C) Telecordia SR 332 Issue 1: Method 1,
case 3
AXB050 8,035,510 Hours
Weight ⎯ 5.70 (0.20) ⎯ g (oz.)
