013-RD000-000-02-201103 56
Appendix B
Specifications
Overview
This appendix contains specification information for the Jaz stack and its individual modules.
Specification Value
Power Consumption 250 mA @ 5 VDC
Computer interface USB in JAZ-DPU module
Ethernet in JAZ-E module
Computer requirements IBM-compatible PC with Pentium or better microprocessor
32 MB RAM (16 MB)
Windows 98/Me/2000/XP, Mac OS X and Linux when using the USB
interface on desktop or notebook PCs.
Operating software SpectraSuite (for an additional $199)
Fiber optic connector SMA 905 to single-strand optical fiber
Spectrometer Module (JAZ-S)
Grating Options 14 different gratings, UV through Shortwave NIR
Detector 2048-element linear silicon CCD array; L2 Collection Lens
Wavelength range 200-1100 nm; maximum 650 nm
Entrance aperture 5, 10, 25, 50, 100 or 200 µm wide slits or fiber (no slit)
AgPlus Mirrors Provide reflectivity >95% over the visible and NIR wavelength range and
over a wide range of angles of incidence
Signal-to-noise ratio 250:1
Integration time 870 µs to 65 seconds
Data transfer rate USB: 60 scans per second
Ethernet: 20 scans per second
