Jaz Stack
Usually consists of up to eight spectrometer modules (JAZ-S), a CPU module (JAZ-DPU), a
battery/memory module (JAZ-B), and an Ethernet/SD module (JAZ-E).
Mini USB Cable (USB-CBL-MINI)
Use this cable to connect your Jaz spectrometer module to a computer running on a Windows,
Mac or Linux operating system.
Ethernet Cable (if an Ethernet module is included)
A 14-foot cable to connect the JAZ-E module to a bridge or switch to access the network.
Power Supply (USB-CBL-PS)
A 5 V power supply to provide an extra power source in addition to the battery, USB power and
POE (Power Over Ethernet).
Wavelength Calibration Data Sheet
Each spectrometer is shipped with a Wavelength Calibration Data Sheet that contains information
unique to your spectrometer. SpectraSuite Operating Software reads this calibration data from
your spectrometer when it interfaces to a computer via the USB port.
Note
Please save the Wavelength Calibration Data Sheet for future reference.
Software and Technical Resources CD
Each order ships with the Ocean Optics Software and Resources CD. This disc contains software,
operating instructions, and product information for all Ocean Optics software, spectrometers, and
spectroscopic accessories. You need Adobe Acrobat Reader version 6.0 or higher to view these
files. Ocean Optics includes the Adobe Acrobat Reader on the Software and Technical Resources
CD.
Ocean Optics software requires a password during the installation process. You can locate
passwords for the other software applications on the back of the Software and Technical
Resources CD package.
Additional Equipment Available
, the following software and accessories are available for use with Jaz. Visit
us at
for a complete list of products available for all of your spectroscopy needs.
JAZ-MNT-DIN3 rail-mounting kit
JAZ-MNT-WALL wall-mounting kit for mounting Jaz stacks with 3 or fewer modules
(excluding the DPU and end module) onto a wall.
JAZ-MOUNT Jaz side-mounting kit for 3 different orientations.
JAZ-CBL-DB15 accessory cable. See
