1: Introduction
013-RD000-000-02-201103 7
 Jaz EL 200-XR1 for both VIS/NIR and UV/VIS applications
 Jaz Spectrometer
 Grating #31 (200-1050 nm)
 Detector 200-1050 nm
 INTSMA-25 (25mm slit)
 L2 light collection lens
 Battery module
 SpectraSuite software
 Jaz-FL-365 for fluorescence applications
 JAZ-COMBO
 JAZ-L365 (365 mm LED module)
 JAZ-B battery module
 JAZ-E Ethernet module
 Grating #2 (250-800 nm)
 Detector 250-800 nm
 INTSMA-200 (200mm slit)
 L2 light collection lens
 SpectraSuite software
 Jaz-FL-450 for fluorescence applications
 JAZ-COMBO
 JAZ-L450 (450 mm LED module)
 JAZ-B battery module
 JAZ-E Ethernet module
 Grating #3 (350-1000 nm)
 Detector 350-1000 nm
 INTSMA-200 (200mm slit)
 L2 light collection lens
 SpectraSuite Operating Software. See About SpectraSuite for more information.
 OmniDriver software driver package for Windows, Mac OSX and Linux operating systems.
 JAZ-A-IRRAD absolute irradiance application.
Available on an SD card for onboard absolute irradiance measurements. See Jaz Absolute
Irradiance Installation and Operation Manual for more information.
 Jaz Scripting Language. Allows you to write scripts for your Jaz system to perform simple data
acquisition, processing and exporting of results to an SD card.
 Jaz Application Programming Interface (API) enables 3 rd party development for Jaz.
 NeoFox Sport
Available as an additional module (JAZ-NEOFOX), when coupled with a probe, light source
module and spectrometer module, the NeoFox Sport offers a turnkey Oxygen and pH sensing
instrument, along with spectrometer functionality in a convenient handheld, portable device. See
NeoFox and NeoFox Sport Installation and Operation Manual for more information.
