4: Operating the JAZ-PX Module
013-RD000-000-02-201103
31
PX Menu Default Values
When you first power-on the Jaz stack, the JAZ-PX module defaults to the following settings:
Setting
Default Value
Parameters Menu
Flash Rate
200Hz (5 ms)
Intensity
400V
Number of Flashes
1
Holdoff Time
1 ms
Timing Controls Menu
Force Trigger
No (N/A)
Timing Reset
No (N/A)
Free Running
Disabled
Run Forever
Disabled
Output Enable
Disabled
Trigger Enable
Enabled
Advanced Settings Menu
Power Mode
Battery Power
Getting Started with the JAZ-PX Module
You can control your JAZ-PX module from the Jaz PX menu (see
) or from SpectraSuite
spectrometer operating software (if you have purchased SpectraSuite and have your Jaz unit attached to a
computer) (see
Operating JAZ-PX from SpectraSuite
For most applications, the JAZ-PX module can be quickly configured for either Continuous Strobe mode
or triggered mode as described below. Also, see
for a list of JAZ-PX menu
defaults.
More in-depth information concerning triggering is located in the JAZ-PX Lamp Module Engineering
note. See
