1: Introduction
2 013-RD000-000-02-201103
Jaz Modules
Jaz consist of a stack of individual spectroscopic instruments specified by the user to suit their unique
application. Modules available for the Jaz stack include the following:
Module Description
JAZ-S Spectrometer and grating (up to 8 can be configured in a stack)
JAZ-DPU Processor (CPU), OLED display and keypad
JAZ-E Ethernet and memory module. Includes one slot for an SD card (up to 2 GB).
JAZ-B Battery (lithium-ion) and memory module. Includes two slots for an SD card (up to 2 GB
each). A Jaz 50-Watt battery extender (JAZ-EXT-BP-50WH) is also available.
JAZ-INDY Industrial module enables communication with RS-232 and RS-485 data standards.
Offers both analog and digital inputs and outputs.
JAZ-PX Pulsed xenon light source
JAZ-UV-VIS Deuterium-tungsten halogen light source
JAZ-VIS-NIR Tungsten-halogen light source
JAZ-INTLED LED module that allows you to replace the following LED assmblies:
- JAZ-L640: 640 nm red LED
- JAZ-L590: 590 nm yellow LED
- JAZ-L450: 470 nm blue LED
- JAZ-L365: 365 nm UV LED
- JAZ-LWHITE: White LED
JAZ-NEOFOX Jaz NeoFox Sport oxygen sensing module for measuring percentage of oxygen.
A Jaz Combo consists of a combination of up to three JAZ-S spectrometer modules and a JAZ-DPU
module.
Features
 Sony ILX511B 2048-element linear silicon CCD array detector
 14 grating options, UV through shortwave NIR
 Responsive from 200 to 1100 nm
 Maximum Wavelength range 650 nm
 Sensitivity of up to 75 photons/count at 400 nm; 41 photons/count at 600 nm
 An optical resolution of ~0.3 to 10.0 nm (FWHM)
 Integration times from 870 µ to 65 seconds
 EEPROM storage for
 Wavelength Calibration Coefficients
