A: Reference
40 000-20000-090-02-1209
Selected Elements
This list contains all atoms and molecules selected for the database search. You can use this list as a
summary and checklist.
Wavelength range
Use this field to specify the wavelength range in which the database should be searched for lines and band
structures of the selected atoms, molecules and ions.
Intensity range
Use this field to specify the intensity range in which the database should be searched for lines and band
structures of the selected atoms, molecules and ions. The units of the specified values must correspond to
the selection in the dialog Display Options dialog box.
Neutrals and Ions (single and multiple ionized)
Use this field to specify which types of the selected elements should be scanned in the line identification
process.
Save as default
Select this option to save the current values as default values when this dialog box is closed.
Display options...
Click this button to open the Display Options dialog box, in which you can change the display of the
results in the spectrum and in the results tables.
Load configuration...
Click this button to load a stored configuration (atom and molecule selection, filter, hit interval,...) for the
database search.
Save configuration...
Click this button to save the current configuration for the database search.
Database search: Display Options
Use this dialog box to control the display of the results in the spectrum and in the results tables. Also see
Line Identification: Display Options ).
