Page 9
2-3 Controller stand
Product Name
Qty
Controller stand assembly
1
Base assembly
1
Base cover
1
Slip ring assembly
1
Controller splitter cord
1
Set screw with hexagonal hole
M4 x 4 long
2
Phillips head tapping screw
4 x 30 (holds base in place)
3
2-4 Function module
Part Name
Qty
Function Module
(including mounting
hardware)
1
(with O-Ring safety sheet)
(Slip Ring inside)
(1 Spare)
9
