3. Dimension Drawings and Specifications
3-1 Bathtub, Controller stand and Function Module
Bathtub
Air blower nozzle
(15 positions)
Headrest base
Air blower
5
2
7
1800
0
1
4
1
7
2
2
684
81 1282 47
56 56
96 671 266 671 96
96 804 804 96
Typ
Typ Typ
Shower Box
Underwater lighting
Drain valve
Underwater lighting
Overflow
Shoulder
warmer pump
Drain elbow
Drainage
direction
Drain Fitting
for 1-1/2”
nominal pipe
Bath connection (TUB) (NPT 3/4)
Shower connection (H) (NPT 1/2)
Shower connection (C) (NPT 1/2)
Water Level Sensor
