(2) Attach the base
➀
Use the screws that came with the base to attach it so that it faces the right direction.
➁
Attach the base cover.
Deck
installation screws
Base
Power
Screwdriver
Protective sheet
Base
Do not remove the protective sheet on the base.
• Doing so could cause problems or make the unit malfunction, due to debris or damage to the O ring.
• This will make it more difficult to install the slip ring and could bend or damage the slip ring.
Prohibited
Base cover
