12
3-2 List of Specifications
AIRBATH™
External Dimensions 70 7/8" x 55 1/2" x 28 1/2" (1800 mm W, 1410 mm D, 725 mm H)
Weight 353 lbs. (160 kg)
Capacity 161 Gallons (610 L) to overflow line
Drain time 9 minutes 15 seconds
Material Acrylic Synthetic Marble
Tub filling
Number of drains 1
Tub filling flow rate Maximum 35 L/min.
Air blower Number of jets 15 on the bottom of the AIRBATH™
Shoulder
warmer
Intake ports 1
Outlet ports 2
Underwater
lighting
Lighting modules 2
Colors
3 types of patterns, 10 individual colors (controlled from the
function module)
Water pressure used (Clean-up shower) 0.08 to 0.75 MPa
Connecting
port diameter
Hot supply (shower) NPT 1/2
Cold supply (shower) NPT 1/2
Fill-tub (hot) NPT 3/4
Other Fill-tub fittings, 2-handle tube cleaning shower, headrest
Controller
Stand
Outside dimensions 9 5/8" x 4 1/2" x 10" (246 mm W, 113 mm D, 255 mm H)
Weight 6.2 lbs. (2.8 kg) (including the controller)
Rotation angle 90 °
Function
Module
Outside dimensions See dimensional diagrams
Weight 37.5 lbs. (17 kg)
Rated voltage 120 VAC
Rated frequency 60 Hz
Rated current 5.9 A
Rated power consumption 710 W
Installation location Indoor
Water pressure
29 to 108.75 psi (0.20 to 0.75 MPa) (The pressure differential of
the cold water is to be greater than that of the hot water and kept
within 0.lMPa.)
water
temperature Hot water supply 140 to 158°F (60 to 70°C)
Cold water supply 32 to 86°F (0 to 30°C) (No freezing)
Connecting
port diameter
Hot water supply NPT 3/4
Cold water supply NPT 3/4
Hater water NPT 3/4
