(3) Install the slip ring
Place the slip ring on the base, being careful not to confuse the front and back surfaces of slip ring holder.
Slit
Front surface
Slip ring holder
Back surface
Slit
Be sure to attach the slip ring.
• Not installing it could bring the base cover and stand into contact and damage the base cover.
Always do this
Install the slip ring very carefully.
• If the slip ring becomes "stretched" or "misshapen", it may not perform its intended function.
Always do this
Remove the slip ring holder from the base while leaving the slip ring in place by tearing off the part of the slip ring
holder with the slit in it to the right and left.
Slip ring
Remove the protective sheet on the base.
Please remove the protective sheet carefully. Otherwise, the slip ring could become damaged or misshapen.
Slip ring
Protective sheet
