ITEM QTY. DESCRIPTION P/N
A 8 Washer, 1/4”ID x 5/16”OD AI1073-00
B 6 Hex Head Screw, 1/4”-20x1.0” AI1131-00
C 6 Speed Clip Nut, 1/4-20 AI1059-00
D 1 Scoop, Main Channel AL1164-00
E 1 Scoop, Base AL1165-00
F 4 Washer, Flat USS, 5/16”ID
x 3/4”OD AI1093-00
G 2 Hex Head Screw, 5/16”-18x3/4” AI1467-00
H 1 Lower Mounting Bracket AI1543-00
I 2 Nut, Hex Nylock, 5/16”-18 AI1298-00
J 1 Loctite 242, .02oz., Blue AI1406-00
K 8 Washer, Split Lock, 1/4” AI1309-00
L 1 Scoop, Plug AL1166-00
M 2 Hex Head Screw, 1/4”-20x3/4” AI1068-00
N
15461 Slover Ave., Fontana, CA 92337 - Phone: (909) 947-0015 - Fax: (909) 947-0603 - www.sbfilters.com
EXPLODED VIEW
P/N: AS-1002
AM0
1
7
7
-0
0
R
e
v.
B
0
4
/2
9
/1
3
5
PERFORMANCE TESTING
• Engage parking brake and start your engine.
Listen for abnormal noises. If an air leak is
detected, re-inspect hoses and connections as
they may need to be repositioned and
tightened.
• S&B FILTERS recommends that you keep
your OE intake system in the event it is
required in the future.
• In order to maintain your warranty, all
connections and components must be
checked periodically for alignment and for
proper tension on all connections. Failure to
do so may void your warranty.
• Use only S&B FILTERS cleaning and oil
products to service your filter. Using any other
brand oil and or cleaners on your S&B air filter
may void your warranty.
RELATED ITEMS FOR YOUR
PURCHASE
• Air Filter Wrap (S&B P/N: WF-1032)
Plug Kit
