One-Channel Hardened Managed Ethernet
Extender
Ports
The Hardened Managed Ethernet Extender provides one Ethernet port RJ-45
(10/100Mbps) port and one Ethernet Extender port.
The Ethernet Extender port, uses RJ-11 and Terminal Block connectors that will auto
senses the speeds 1/3/5/10/15/20/25/30/40/50Mbps.
Ethernet Extender Mode Settings
Ethernet Extender mode settings are DIP switch (Dual Inline Package) selectable.
The switch is located on the top panel of the Hardened Managed Ethernet Extender.
DIP switch
There is one pin on the DIP switch for Ethernet Extender mode settings.
One unit must be set to LOC and one to RMT.
Loc Rmt
The device operates in local mode The device operates in remote mode
