36 Manual Documentation Number: EIRM-EXTEND-1412m
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Specifications
Applicable Standards
IEEE802.3 10Base-T, IEEE802.3u 100Base-
TX,
Ethernet over VDSL
Fixed Ports 1 x 10/100Mbps Ethernet port with RJ-45 connector
1 x Ethernet Extender port with RJ-11 and Terminal
Block connectors
Speed
10Base-T
100Base-TX
Ethernet Extender
10/20Mbps for half/full-duplex
100/200Mbps for half/full-duplex
1, 3, 5, 10, 15, 20, 25, 30, 40, 50Mbps
Switching Method Store-and-Forward
Forwarding rate 14,880/148,810pps for 10/100Mbps
Cable
10Base-T
100Base-TX
Ethernet Extender 2-pair UTP/STP Cat. 3, 4, 5 up to 100m
2-pair UTP/STP Cat. 5 up to 100m
Telephone wires
LED Indicators Per Unit (3 LEDs)- Power1, Power2, Power3
Per Port-
RJ-45 (2 LEDs): Link/ACT, FDX
RJ-11, Terminal Block (9 LEDs): Remote,
Local, Error, Link, 1, 2, 3, 4, 5
Dimensions 50mm (W) × 110mm (D) x 135mm (H)
(1.97” (W) x 4.33” (D) x 5.31” (H))
Weight 0.8Kg (1.76lbs.)
Power
Terminal Block: 12-32VDC
DC Jack: 12VDC, External AC/DC required
Operating Voltage &
Max.
Current Consumption 0.5A @ 12VDC, 0.25A @ 24VDC
Power Consumption 6W Max.
Operating Temperature
-40°C ~ 75°C (-40 ℉ ~ 167℉)
Tested for functional operation @
-40°C ~ 85°C (-40 ℉ ~ 185℉)
UL508 Industrial Control Equipment certified
Maximum Surrounding Air Temperature @
75 (167
℉)
Storage Temperature -40°C ~ 85°C (-40°F ~ 185°F)
Humidity 5 ~ 95%, non-condensing
Safety UL508, EN60950-1, IEC60950-1
