Chapter 3 – Command Line Console
Management
The Hardened Managed Ethernet Extender provides a command line console
interface for configuration purposes. The Hardened Managed Ethernet Extender can
be configured either locally through its RS-232 port or remotely via a Telnet session.
For the later, you must specify an IP address for the switch first.
This chapter describes how to configure the Hardened Managed Ethernet Extender
using its console by Commend Line.
Connect the DB9 straight cable to the DCE female RS-232 serial port of the device to
the DTE male RS-232 serial port of the terminal or computer running the terminal
emulation application.
Direct access to the administration console is achieved by directly connecting a
terminal or a PC equipped with a terminal-emulation program (such as
HyperTerminal) to the Hardened Managed Ethernet Extender console port.
When using the management method, configure the terminal-emulation program to
use the following parameters (you can change these settings after login):
[Default parameters]
115,200bps
8 data bits
No parity
1 stop bit
At the login: prompt just type in “root” and press .
At the Password: prompt just press to logon to the Hardened Managed
Ethernet Extender.
Manual Documentation Number: EIRM-EXTEND-1412m 25
