Page 35
Chapter 5 Management
5.1 SNMP Management
The EKI-6311GN supports SNMP for convenient remote management. Open “SNMP Configuration” in
“Management” shown below. Set the SNMP parameters and obtain MIB file before remote
management.
Figure 31 SNMP Configuration
Enable SNMP
Check this box to enable SNMP settings.
Protocol Version
Select the SNMP version, and keep it identical on the EKI-6311GN and the SNMP manager.
Server Port
Change the server port for a service if needed; however you have to use the same port to use that
service for remote management.
Get Community
Specify the password for the incoming Get and GetNext requests from the management station. By
default, it is set to public and allows all requests.
Set Community
Specify the password for the incoming Set requests from the management station. By default, it is
set to private.
Trap Destination
Specify the IP address of the station to send the SNMP traps to.
Trap Community
