Page 17
6311GN is 192.168.1.1. (X cannot be 0, 1, nor 255);
A Web browser on PC for configuration such as Microsoft Internet Explorer 6.0 or above,
Netscape or Firefox.
3.3 How to Login the Web-based Interface
The EKI-6311GN provides you with user-friendly Web-based management tool.
Open Web browser and enter the IP address (Default: 192.168.1.1) of EKI-6311GN into the
address field. You will see the login page as below.
Figure 10 Login Page
Enter the username (Default: admin) and password (Default: password) respectively and click
“Login” to login the main page of EKI-6311GN. As you can see, this management interface
provides five main options in the black bar above, which are Status, System, Wireless,
Management and Tools.
