SUPPLY CURRENT
vs. TEMPERATURE
MAX3301E toc15
TEMPERATURE (
°C)
SUPPLY CURRENT (mA)
60
35
10
-15
0.2
0.4
0.6
0.8
1.0
0
-40
85
V
BUS
OFF
FULL-SPEED IDLE
V
CC
= 3.3V
V
CC
= 4.2V
DRIVER DISABLE DELAY
(LOW-SPEED MODE)
MAX3301E toc14
10ns/div
D+
1V/div
D-
1V/div
OE/INT
1V/div
DRIVER ENABLE DELAY
(LOW-SPEED MODE)
MAX3301E toc13
100ns/div
D-
1V/div
D+
1V/div
C
D+
= C
D-
= 400pF
OE/INT
1V/div
DRIVER DISABLE DELAY
(FULL-SPEED MODE)
MAX3301E toc12
10ns/div
D+
1V/div
D-
1V/div
OE/INT
1V/div
DRIVER ENABLE DELAY
(FULL-SPEED MODE)
MAX3301E toc11
10ns/div
D-
1V/div
D+
1V/div
OE/INT
1V/div
DRIVER PROPAGATION DELAY LOW-TO-HIGH
(FULL-SPEED MODE)
MAX3301E toc10
4ns/div
D-
1V/div
D+
1V/div
DAT_VP
1V/div
MAX3301E
USB On-the-Go Transceiver and Charge Pump
8
_______________________________________________________________________________________
Typical Operating Characteristics (continued)
(Typical operating circuit, V
CC
= +3.7V, V
L
= +2.5V, C
FLYING
= 100nF, T
A
= +25°C, unless otherwise noted.)
