MAX3301E

USB On-the-Go Transceiver and Charge Pump

14

______________________________________________________________________________________

MODE

I

2

C

ID_IN

sess_end

COMP

sess _vld

COMP

vbus_ vld

COMP

cr_int

COMP

dp_hi

COMP

dm_hi

COMP

TRM

TX

DIFF

RX

SE
RX

Shutdown

1

X

X

X

X

X

X

X

X

X

X

X

Interrupt

Shutdown

2

X

X

X

X

X

X

X

Suspend

3

X

Normal

Operating

Table 1. Functional Blocks Enabled During Specific Operating Modes

= Enabled.

X = Disabled.

1. Enter shutdown mode by writing a 1 to sdwn (bit 0 of special-function register 2).

2. Enter interrupt shutdown mode by writing a 1 to int_sdwn (bit 0 of special-function register 1).

3. Enter suspend mode by writing a 1 to spd_susp_ctl (bit 1 of special-function register 1) and suspend (bit 1 of control register 1), or

by writing a 0 to spd_susp_ctl (bit 1 of special-function register 1) and driving SUS high.

ID_IN

The USB OTG specification defines an ID input that
determines which dual-role device is the default host.
An OTG cable connects ID to ground in the connector
of one end and is left unconnected in the other end.
Whichever dual-role device receives the grounded end
becomes the A device. The MAX3301E provides an
internal pullup resistor on ID_IN. Internal comparators
detect if ID_IN is grounded or left floating.

Interrupt Logic

When OTG events require action, the MAX3301E pro-
vides an interrupt output signal on INT. Alternatively,
OE/INT can be configured to act as an interrupt output
while the device operates in USB suspend mode.
Program INT and OE/INT as open-drain or push-pull
interrupts with irq_mode (bit 1 of special-function regis-
ter 2, see Table 15).

V

BUS

Power Control

V

BUS

is a dual-function port that powers the USB bus

and/or provides a power source for the internal linear reg-
ulator. The V

BUS

power-control block performs the various

switching functions required by an OTG dual-role device.
These actions are programmed by the system logic using
bits 5 to 7 of control register 2 (see Table 8) to:

Discharge V

BUS

through a resistor

Provide power-on or receive power from V

BUS

Charge V

BUS

through a resistor

The OTG supplement allows an A device to turn V

BUS

off when the bus is not being used to conserve power.
The B device can issue a request that a new session be
started using SRP. The B device must discharge V

BUS

to a level below the session-end threshold (0.8V) to

ensure that no session is in progress before initiating
SRP. Setting bit 6 of control register 2 to a 1, discharges
V

BUS

to GND through a 5k

Ω current-limiting resistor.

When V

BUS

has discharged, the resistor is removed

from the circuit by resetting bit 6 of control register 2.

An OTG A device is required to supply power on V

BUS

.

The MAX3301E provides power to V

BUS

from V

CC

or

from the internal charge pump. Set bit 5 in control regis-
ter 2 to a 1 in both cases. Bit 5 in control register 2 con-
trols a current-limited switch, preventing damage to the
device in the event of a V

BUS

short circuit.

An OTG B device (peripheral mode) can request a ses-
sion using SRP. One of the steps in implementing SRP
requires pulsing V

BUS

high for a controlled time. A 930

resistor limits the current according to the OTG specifi-
cation. Pulse V

BUS

through the pullup resistor by assert-

ing bit 7 of control register 2. Prior to pulsing V

BUS

(bit

7), a B device first connects an internal pulldown resis-
tor to discharge V

BUS

below the session-end threshold.

The discharge current is limited by the 5k

Ω resistor and

set by bit 6 of control register 2. An OTG A device must
supply 5V power and at least 8mA on V

BUS

. Setting bit

5 of control register 2 turns on the V

BUS

charge pump.

Operating Modes

The MAX3301E has four operating modes to optimize
power consumption. Only the I

2

C interface remains active

in shutdown mode, reducing supply current to 1µA. The
I

2

C interface, the ID_IN port, and the session-valid com-

parator all remain active in interrupt shutdown mode. RCV
asserts low in suspend mode; however, all other circuitry
remains active. Table 1 lists the active blocks’ power in
each of the operating modes.
