MAX3301E
USB On-the-Go Transceiver and Charge Pump
_______________________________________________________________________________________
3
DC ELECTRICAL CHARACTERISTICS (continued)
(V
CC
= +3V to +4.5V, V
L
= +1.65V to +3.6V, C
FLYING
= 100nF, C
VBUS
= 1µF, ESR
CVBUS
= 0.1
Ω (max), T
A
= T
MIN
to T
MAX
, unless
otherwise noted. Typical values are at V
CC
= +3.7V, V
L
= +2.5V, T
A
= +25°C.) (Note 2)
PARAMETER
SYM B O L
CONDITIONS
MIN
TYP
MAX
UNITS
OE/INT, SPD, SUS, RESET
DAT_VP, SE0_VM Input Low
Voltage
V
IL
0.4
V
ADD Input High Voltage
V
IHA
2/3 x V
L
V
ADD Input Low Voltage
V
ILA
1/3 x V
L
V
Input Leakage Current
±1
µA
TRANSCEIVER SPECIFICATIONS
Differential Receiver Input
Sensitivity
|V
D+
- V
D-
|
0.2
V
Differential Receiver Common-
Mode Voltage
0.8
2.5
V
Single-Ended Receiver Input Low
Voltage
V
ILD
D+, D-
0.8
V
Single-Ended Receiver Input
High Voltage
V
IHD
D+, D-
2.0
V
S i ng l e- E nd ed Recei ver H yster esi s
0.2
V
S i ng l e- E nd ed Outp ut Low V ol tag e
V
OLD
D+, D-, R
L
= 1.5k
Ω from D+ or D- to 3.6V
0.3
V
S i ng l e- E nd ed Outp ut H i g h V ol tag e
V
OHD
D+, D-, R
L
= 15k
Ω from D+ or D- to GND
2.8
3.6
V
Off-State Leakage Current
D+, D-
±1
µA
Low steady-state drive
2
13
Driver Output Impedance
D+, D-, not
including R
EXT
High steady-state drive
2
13
Ω
ESD PROTECTION (V
BUS
, ID_IN, D+, D-)
Human Body Model
±15
kV
IEC 61000-4-2 Air-Gap Discharge
±10
kV
IEC 61000-4-2 Contact Discharge
±6
kV
THERMAL SHUTDOWN
Thermal Shutdown Low-to-High
+160
o
C
Thermal Shutdown High-to-Low
+150
o
C
CHARGE-PUMP SPECIFICATIONS (vbus_drv = 1)
V
BUS
Output Voltage
V
BUS
3V < V
C C
< 4.5V, C
V BUS
= 10µF, I
V BUS
= 8m A
4.80
5.25
V
V
BUS
Output Current
I
VBUS
8
mA
V
BUS
Output Ripple
I
VBUS
= 8mA, C
VBUS
= 10µF
100
mV
