MAX7032
Low-Cost, Crystal-Based, Programmable,
ASK/FSK Transceiver with Fractional-N PLL
22
______________________________________________________________________________________
BIT ID
BIT NAME
BIT LOCATION (0 = LSB)
FUNCTION
AGCLK
AGC locking feature
7
1 = Enable AGC lock
0 = Disable AGC lock
GAIN
Gain state
6
1 = Force manual high-gain state if MGAIN = 1
0 = Force manual low-gain state if MGAIN = 1
TRK_EN
Manual peak-detector
tracking
5
1 = Force manual peak-detector tracking
0 = Release peak-detector tracking
X
None
4
Not used
PCAL
Polling timer calibration
3
1 = Perform polling timer calibration
Automatically reset to zero once calibration is completed
FCAL
FSK calibration
2
1 = Perform FSK calibration
Automatically reset to zero once calibration is completed
CKOUT
Crystal clock output enable
1
1 = Enable crystal clock output
0 = Disable crystal clock output
SLEEP
Sleep mode
0
1 = Deep-sleep mode, regardless the state of
ENABLE pin
0 = Normal operation
Table 6. Control Register (Address: 0x01)
BIT ID
BIT NAME
BIT LOCATION (0 = LSB)
FUNCTION
LNA
LNA enable
7
1 = Enable LNA
0 = Disable LNA
AGC
AGC enable
6
1 = Enable AGC
0 = Disable AGC
MIXER
Mixer enable
5
1 = Enable mixer
0 = Disable mixer
BaseB
Baseband enable
4
1 = Enable baseband
0 = Disable baseband
PkDet
Peak-detector enable
3
1 = Enable peak detector
0 = Disable peak detector
PA
Transmitter PA enable
2
1 = Enable PA
0 = Disable PA
RSSIO
RSSI amplifier enable
1
1 = Enable buffer
0 = Disable buffer
X
None
0
Not used
Table 5. Power-Configuration Register (Address: 0x00)
