General Description

The MAX19995 dual-channel downconverter provides
up to 9dB of conversion gain, +24.8dBm input IP3,
+13.3dBm 1dB input compression point, and a noise
figure as low as 9dB for 1700MHz to 2200MHz diversity
receiver applications. With an optimized LO frequency
range of 1400MHz to 2000MHz, this mixer is ideal for
low-side LO injection architectures. High-side LO injec-
tion is supported by the MAX19995A, which is pin-pin
and functionally compatible with the MAX19995.

In addition to offering excellent linearity and noise per-
formance, the MAX19995 also yields a high level of
component integration. This device includes two dou-
ble-balanced passive mixer cores, two LO buffers, a
dual-input LO selectable switch, and a pair of differen-
tial IF output amplifiers. Integrated on-chip baluns allow
for single-ended RF and LO inputs.

The MAX19995 requires a nominal LO drive of 0dBm
and a typical supply current of 297mA at V

CC

= 5.0V or

212mA at V

CC

= 3.3V.

The MAX19995/MAX19995A are pin compatible with
the MAX19985/MAX19985A series of 700MHz to
1000MHz mixers and pin similar with the MAX19997A/
MAX19999 series of 1800MHz to 4000MHz mixers,
making this entire family of downconverters ideal for
applications where a common PCB layout is used
across multiple frequency bands.

The MAX19995 is available in a 6mm x 6mm, 36-pin
thin QFN package with an exposed pad. Electrical per-
formance is guaranteed over the extended temperature
range, from T

C

= -40°C to +85°C.

Applications

UMTS/WCDMA/LTE Base Stations

cdma2000

®

Base Stations

DCS1800 and EDGE Base Stations

PCS1900 and EDGE Base Stations

PHS/PAS Base Stations

Fixed Broadband Wireless Access

Wireless Local Loop

Private Mobile Radios

Military Systems

Features

1700MHz to 2200MHz RF Frequency Range
1400MHz to 2000MHz LO Frequency Range
1750MHz to 2700MHz LO Frequency Range

(MAX19995A)

50MHz to 500MHz IF Frequency Range
9dB Typical Conversion Gain
9dB Typical Noise Figure
+24.8dBm Typical Input IP3
+13.3dBm Typical Input 1dB Compression Point
79dBc Typical 2RF-2LO Spurious Rejection at

P

RF

= -10dBm

Dual Channels Ideal for Diversity Receiver

Applications

49dB Typical Channel-to-Channel Isolation
Low -3dBm to +3dBm LO Drive
Integrated LO Buffer
Internal RF and LO Baluns for Single-Ended

Inputs

Built-In SPDT LO Switch with 56dB LO-to-LO

Isolation and 50ns Switching Time

Pin Compatible with the MAX19985/MAX19985A/

MAX19995A Series of 700MHz to 2200MHz Mixers

Pin Similar to the MAX19997A/MAX19999 Series

of 1800MHz to 4000MHz Mixers

Single +5.0V or +3.3V Supply
External Current-Setting Resistors Provide Option

for Operating Device in Reduced-Power/Reduced-
Performance Mode

MAX19995

Dual, SiGe, High-Linearity, 1700MHz to 2200MHz

Downconversion Mixer with LO Buffer/Switch

________________________________________________________________

Maxim Integrated Products

1

Ordering Information

19-4253; Rev 0; 12/08

For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,
or visit Maxim’s website at www.maxim-ic.com.

cdma2000 is a trademark of Telecommunications Industry
Association.

PART

TEMP RANGE

PIN-PACKAGE

MAX19995ETX+

-40°C to +85°C

36 Thin QFN-EP*

MAX19995ETX+T

-40°C to +85°C

36 Thin QFN-EP*

Pin Configuration and Typical Application Circuit appear at
end of data sheet.

+

Denotes a lead(Pb)-free/RoHS-compliant package.

*

EP = Exposed pad.

T = Tape and reel.
