RF02

9

MOD

DI

Connect to logic high

10

RFN

AO

Power amplifier output (open collector)

11

RFP

AO

Power amplifier output (open collector)

12

nIRQ

DO Interrupt request output for microcontroller (active low) and status read output

13

VDD_RF S

RF VDD(Connect to VDD)

14

VDD_A

S

Analog VDD(Connect to VDD)

15

VDD_D

S

Digital VDD(Connect to VDD)

16

FSK

DI

Serial data input for FSK modulation

Typical application
