29

U3742BM

4735A–RKE–11/03

Sensitivity variation FSK for the full
operating range compared to
T

amb

= 25

°

C, V

S

= 5 V

f

in

= 433.92 MHz/315 MHz

f

IF

= 1 MHz

P

FSK

= P

Ref_FSK

+

D

P

Ref

D

P

Ref

+2.5

-1.5

dB

Sensitivity variation FSK for full
operating range including IF filter
compared to T

amb

= 25

°

C, V

S

= 5 V

f

in

= 433.92 MHz/315 MHz

f

IF

= 0.86 MHz to 1.14 MHz

f

IF

= 0.82 MHz to 1.18 MHz

P

FSK

= P

Ref_FSK

+

D

P

Ref

D

P

Ref

+5.5
+7.5

-1.5
-1.5

dB
dB

FSK frequency deviation

The sensitivity of the receiver is higher
for higher values of

D

f

FSK

BR_Range0
BR_Range1
BR_Range2 and BR_Range3 are not
suitable for FSK operation

D

f

FSK

20
20

30
30

50
50

kHz
kHz

S/N ratio to suppress inband noise
signals

ASK mode
FSK mode

SNR

ASK

SNR

FSK

10

2

12

3

dB
dB

Dynamic range RSSI amplifier

D

R

RSSI

60

dB

Lower cut-off frequency of the data
filter

f

cu_DF

0.11

0.16

0.20

kHz

Recommended CDEM for best
performance

ASK mode
BR_Range0 (Default)
BR_Range1
BR_Range2
BR_Range3

CDEM

39
22
12

8.2

nF
nF
nF
nF

Recommended CDEM for best
performance

FSK mode
BR_Range0 (Default)
BR_Range1
BR_Range2 and BR_Range3 are not
suitable for FSK operation

CDEM

27
15

nF
nF

Maximum edge-to-edge time period of
the input data signal for full sensitivity

BR_Range0 (Default)
BR_Range1
BR_Range2
BR_Range3

t

ee_sig

1000

560
320
180

µs
µs
µs
µs

Upper cut-off frequency data filter

Upper cut-off frequency programmable
in 4 ranges via a serial mode word
BR_Range0 (Default)
BR_Range1
BR_Range2
BR_Range3

f

u

2.5
4.3
7.6

13.6

3.1
5.4
9.5

17.0

3.7
6.5

11.4
20.4

kHz
kHz
kHz
kHz

Minimum edge-to-edge time period of
the input data signal for full sensitivity

BR_Range0 (Default)
BR_Range1
BR_Range2
BR_Range3

t

ee_sig

270
156

89
50

µs
µs
µs
µs

Reduced sensitivity

R

Sense

connected from pin Sens to V

S

,

input matched according to Figure 6

P

Ref_Red

dBm

(peak

level)

Electrical Characteristics (Continued)

All parameters refer to GND, T

amb

= -40°C to +105°C, V

S

= 4.5 V to 5.5 V, f

0

= 433.92 MHz and f

0

= 315 MHz, unless other-

wise specified. (V

S

= 5 V, T

amb

= 25°C)

Parameters

Test Conditions

Symbol

Min.

Typ.

Max.

Unit

f

cu_DF

1

2

p

´

30 k

W

´

CDEM

´

-----------------------------------------------------------

=
