U3742BM
4735A–RKE–11/03
Table 3. Effect of the Configuration Words within the Registers
Table 4. Effect of the Configuration Word BR_Range
Table 5. Effect of the Configuration Word N
Bitcheck
Table 6. Effect of the Configuration Bit Reserved
Bit 1 Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Bit 8
Bit 9
Bit 10
Bit 11
Bit 12
Bit 13
Bit 14
OFF Command
1
OPMODE Register
0
1
BR_Range
N
Bitcheck
V
POUT
Sleep
XSleep
0
1
Baud1
Baud0
BitChk1
BitChk0
POUT
Sleep4
Sleep3
Sleep2
Sleep1
Sleep0
X
Sleep Std
X
Sleep Temp
(Default)
0
0
1
0
0
0
1
0
1
1
0
0
LIMIT Register
0
0
Lim_min
Lim_max
0
0
Lim_min5 Lim_min4 Lim_min3 Lim_min2 Lim_min1 Lim_min0 Lim_max5 Lim_max4 Lim_max3 Lim_max2 Lim_max1 Lim_max0
(Default)
0
0
1
1
1
0
0
1
1
0
0
0
BR_Range
Baud Rate Range/Extension Factor for Bit Check Limits (XLim)
Baud1
Baud0
0
0
BR_Range0 (application USA/Europe: BR_Range0 = 1.0 kBaud to 1.8 kBaud) (Default)
XLim = 8 (Default)
0
1
BR_Range1 (application USA/Europe: BR_Range1 = 1.8 kBaud to 3.2 kBaud)
XLim = 4
1
0
BR_Range2 (application USA/Europe: BR_Range2 = 3.2 kBaud to 5.6 kBaud)
XLim = 2
1
1
BR_Range3 (Application USA/Europe: BR_Range3 = 5.6 kBaud to 10 kBaud)
XLim = 1
N
Bitcheck
Number of Bits to be Checked
BitChk1
BitChk0
0
0
0
0
1
3
1
0
6 (Default)
1
1
9
Reserved Bit
No Function (Reserved for Future Use)
0
(Default)
1
