Non-laminated stiffener to sidewall detail, Stiffener instruction (outside stiffened) – Grain Systems Tanks PNEG-1000 User Manual
Page 72
11. Stiffener Instruction (Outside Stiffened)
72
PNEG-1000 2.66" Commercial Tank Stiffener and Sidewall
Non-Laminated Stiffener to Sidewall Detail
Figure 11M Outside Stiffened Non-Laminated Stiffener to Sidewall Detail
Ref #
Description
A
3/8" Bin Bolt with a Steel Backed Neoprene Washer
B
3/8" Flange Nut (S-456)
C
Non-Laminated Stiffener
D
Outside of Bin
