9. Stiffener Instruction (Inside Stiffened)

PNEG-1000 2.66" Commercial Tank Stiffener and Sidewall

39

2.66'' Corrugation Commercial Stiffeners Splice Details (Continued)

Figure 9D

Ref #

Description

A

Bolt hole not used in 14 gauge and 15 gauge. Do not drill.

B

14 Gauge and 15 Gauge to 14 Gauge and 15 Gauge Offset Connection Detail

C

14 Gauge and 15 Gauge to 13 Gauge and 12 Gauge Offset Connection Detail
