7. Caulking Detail

PNEG-1000 2.66" Commercial Tank Stiffener and Sidewall

27

Caulking Detail (Standard Non-Laminated Sheets) (Continued)

NOTE: See

Figure 7B

for additional details on laminated caulking.

Figure 7B As Viewed from Inside of Bin (Externally stiffened reverse-rolled sheets shown.)

Ref #

Description

A

Double Punch Caulking Detail

B

Triple Punch Caulking Detail

C

Quad Punch Caulking Detail
