Output Connector
BNC
Output Level
800 mV, nominal
Jitter Demod
Displays pk-pk jitter as a bar graph and numeric readout, jitter waveform or
frequency spectrum
Bar Graph
0 to 1 UI or 0 to 0.2 UI with numeric readout
Filter
10 Hz ±2 Hz
1 kHz ±5%
10 kHz ±5%
100 kHz ±5%
Waveform
Synchronized with video
1 H, 2 H, 1 V or 2 V sweep rate
Line-select may be applied
Frequency Plot
Displays a frequency histogram from the filter setting up to a maximum frequency
of 1 or 5 MHz
Eye Parameter Measurement
Amplitude, rise time, fall time
Measurement Bandwidth
250 kHz to 2250 MHz
-3 to 1 dB relative to 750 MHz
Filters
10 Hz ±2 Hz
100 Hz ±10 Hz
1 kHz ±100 Hz
Amplitude
±2% with a displayed waveform of 800 mV
Overshoots
±2% with a displayed overshoot of 10%
20% maximum
Rise and Fall Time
Within 2% of the displayed rise/fall time
Analog Input Module (TVM-VTM-ACV-2)
2 passive looping NTSC/PAL composite video, auto-detect
Signal Level
1 V pk-pk
Input Impedance
Hi-Z, looping
Return Loss
≤-45 dB 100 kHz to 5 MHz
DC Restore Clamp Time
Back Porch
DC Restorer Level Shift Due to
Presence or Absence of Burst
≤1 IRE/ Unit
DC Restorer Level Shift with
Change from 50% APL to 10% APL
or to 90% APL
≤1 IRE/ Unit
DC Restorer 60 Hz Attenuation
Slow
≤5%
Fast
≥90%
Maximum Input Amplitude
(AC+DC) +2.5 to -1.5 VDC restorer off, ±3.0 VDC restorer on
