6 Series Plenum - CATVP (Plenumax ® ® )
18 gauge [0.040 in (1.02 mm)] copper covered steel center conductor; gas expanded Teflon ® dielectric (FEP); inner
shield aluminum laminated tape with overlap bonded to dielectric; outer shield of 34 AWG bare aluminum braid wire;
jacket of plenum rated material. Nom. O.D. 0.237 in. (6.20 mm).
Catalog Number Description Cable Weight Shipping Weight
lbs/kft (kg/km) lbs/kft (kg/km)
2275V (Vinyl Jacket Version) Foam FEP dielectric, bonded tape, 29 (43) 33 (49)
60% braid, plenum rated jacket
2276V (Vinyl Jacket Version) Foam FEP dielectric, bonded tape, 30 (45) 33 (49)
90% braid, plenum rated jacket
2227V (Vinyl Jacket Version) Foam FEP dielectric, bonded tape, 32 (48) 35 (52)
2227K (Kynar Jacket Version) 60% braid, non-bonded tape, 40% braid,
plenum rated jacket
Physical Dimensions Standard Shield Super-Shield
inches (mm) inches (mm)
Nominal Center Conductor Diameter 0.040 (1.02) 0.040 (1.02)
Nominal Diameter Over Dielectric 0.170 (4.57) 0.180 (4.57)
Nominal Diameter Over First Shield (Tape) 0.176 (4.75) 0.187 (4.75)
Nominal Diameter Over Jacket 0.237 (6.20) 0.284 (7.21)
Nominal Jacket Wall Thickness 0.016 (0.41) 0.020 (0.51)
Electrical Characteristics
Nominal Impedance 75 Ohms
Telephone: Nationwide: Fax: E-mail: Internet:
05/04
Comm/Scope Plenumax Coaxial Ca
ble
215-675-2053 800-523-5947 215-675-7543 [email protected] http://www.tonercable.com
969 Horsham Road
Horsham, Pennsylvania 19044 USA
PLENUMAX Coaxial CATV Cable
11 Series Plenum - CATVP (Plenumax ® ® )
14 gauge [0.064 in (1.45 mm)] copper covered steel center conductor; gas expanded Teflon ® dielectric (FEP); inner
shield aluminum laminated tape with overlap bonded to dielectric; outer shield of 34 AWG bare aluminum braid wire;
jacket of plenum rated material. Nom. O.D. 0.351 in (8.92 mm).
Catalog Number Description Cable Weight Shipping Weight
lbs/kft (kg/km) lbs/kft (kg/km)
2285K (Kynar Jacket Version) Foam FEP dielectric, bonded tape, 57 (85) 64 (95)
60% braid, plenum rated jacket
2287K (Kynar Jacket Version) Foam FEP dielectric, bonded tape, 60% braid, 66 (98) 73 (109)
non-bonded tape, 40% braid , plenum rated jacket
Physical Dimensions Standard Shield Super-Shield
inches (mm) inches (mm)
Nominal Center Conductor Diameter 0.064 (1.63) 0.064 (1.63)
Nominal Diameter Over Dielectric 0.280 (7.11) 0.280 (7.11)
Nominal Diameter Over First Shield (Tape) 0.286 (7.26) 0.287 (7.29)
Nominal Diameter Over Jacket 0.351 (8.92) 0.372 (9.45)
Nominal Jacket Wall Thickness 0.020 (0.51) 0.020 (0.51)
Electrical Characteristics
Nominal Impedance 75 Ohms
Attenuation [@ 68°F (20°C)]
Frequency Typical Typical
(MHz) (dB/100 ft) (dB/100 m)
1 0.38 1.25
10 0.70 2.30
50 1.48 4.85
100 2.01 6.59
200 2.86 9.38
400 4.23 13.87
700 5.96 19.55
900 6.96 22.83
1000 7.45 24.44
Attenuation [@ 68°F (20°C)]
Frequency Typical Typical
(MHz) (dB/100 ft) (dB/100 m)
1 0.20 0.66
10 0.45 1.48
50 0.90 2.95
100 1.28 4.20
200 1.85 6.07
400 2.75 9.02
700 3.92 12.86
900 4.72 15.48
1000 5.04 16.53
