SPECIFICATIONS

VIDEO

HD/SD-SDI Input Module (TVM-VTM-SDI-H)

Two passive looping inputs accepting SD SMPTE 259M-C formats or HD SMPTE 292M formats, including: 525/59.94,
625/50, 1080i/60, 1080i/59.94, 1080i/50, 1080p/30, 1080p/29.97, 1080p/25, 1080p/24, 1080p/23.98, 1080p/30sF,
1080p/29.97sF, 1080p/25sF, 1080p/24sF, 1080p/23.98sF, 720p/60, 720p/59.94, 720p/50, 720p/30, 720p/29.97,
720p/24 and 720p/23.98

Data Rate

270 Mb/s, 1.485 Gb/s, auto-detect

Connectors

4 BNCs, Hi-Z passive looping

Level

800 mV, nominal

Input EQ

270 Mb/s: 250 m of 8281
1.485 Gb/s: 100 m of 8281

Return Loss

≤-15 dB, 5 MHz to 1.485 GHz

SDI Monitor Output

Follows the selected digital input

Data Rate

270 Mb/s and 1.485 Gb/s

Connector

BNC

Level

800 mV, nominal

SD-SDI Input Module (TVM-VTM-SDI-S)

Two passive looping SMPTE 259M-C inputs, auto-detect 525/59.94, 625/50

Input Impedance

Hi-Z, looping

Input EQ

Up to 250 m, Belden 8281 at 270 Mb/s

Return Loss

≤-25 dB 5 to 270 MHz

3G/HD/SD-SDI Input Module (TVM-VTM-3GB)

Two passive looping inputs accepting 3 Gb/s SMPTE 424M inputs, SD SMPTE 259M-C formats or HD SMPTE 292M
formats, including: 525/59.94, 625/50, 1080i/60, 1080i/59.94, 1080i/50, 1080p/60, 1080p/59.94, 1080p/50, 1080p/30,
1080p/29.97, 1080p/25, 1080p/24, 1080p/23.98, 1080p/30sF, 1080p/29.97sF, 1080p/25sF, 1080p/24sF,
1080p/23.98sF, 720p/60, 720p/59.94, 720p/50, 720p/30, 720p/29.97, 720p/24 and 720p/23.98

Data Rate

270 Mb/s, 1.485 Gb/s, 2.97 Gb/s, auto-detect

Input Impedance

75 ohms, active looping

Input EQ

Up to 250 m, Belden 8281 at 270 Mb/s, 100 m, Belden 8281 at 1.485 Gb/s or 80
m, Belden 1694A at 2.97 Gb/s

Return Loss

≤-25 dB, 5 to 270 MHz; ≤-15 dB, 270 MHz to 1.5 GHz; ≤-10 dB, 1.5 to 2.97 GHz

Connector

BNC
