NEXIO Volt Integrated Storage Server

NEXIO Volt Shared Storage Server

NEXIO Volt Rear Panel View

◦ Multiple audio Lissajous displays

7903.*

0XOWLIRUPDW*+'6'

9LGHR:DYHIRUP0RQLWRUDQG$XGLR6LJQDO$QDO\]HU

▪ Dual, auto-detecting SDI input for 3 Gb/s, HD or SD
▪ Dual, auto-detecting NTSC/PAL analog composite option
▪ Single-input ASI monitoring option
▪ 3D analysis upgrade with multiple 3D formats and displays
▪ Standards: SMPTE 424M, SMPTE 292M, SMPTE 259M-C, NTSC/PAL
▪ Multiple reference inputs
▪ Simultaneous display of up to four different inputs
▪ Customizable display functions, including screen location and multiple displays
▪ Patented video relative timing display
▪ Patented gamut display
▪ Pixel locator/data word analyzer
▪ Multiple-picture thumbnail
▪ A/B parade and overlay
▪ 608, 708 closed-caption detect, alarm, display
▪ Teletext detect, alarm, display
▪ OP-47 HD subtitle display
▪ Comprehensive alarm set with peak level report
▪ 16 direct-access user presets
▪ Integral high-brightness XGA TFT color LCD display
▪ Illuminated controls and indicators
▪ DVI-I output
▪ USB port for control and data transfer
▪ 10/100Base-T Ethernet, SNMP agent
▪ Web server
▪ SpyderWeb II remote control and logging software
▪ GPI control

FEATURES

Selectable Options
▪ Video inputs

◦ Dual HD/SD-SDI
◦ Dual HD/SD-SDI with eye pattern
◦ Dual HD/SD-SDI with eye pattern and jitter
waveform and spectrum display
◦ 3D analysis
◦ Dual 3G/HD/SD-SDI with RGB dual link
◦ Dual ASI
◦ Dual composite analog

▪ Audio

◦ Metering and monitoring of up to eight channels of

analog, AES/EBU and embeddedaudio

◦ Dolby® Digital, Dolby Surround EX, Dolby E,
'olby Pro-Logic® I formats
◦ Dolby decoded outputs
◦ Loudness metering and alarm
◦ Multiple audio Lissajous displays
