ORDERING INFORMATION

Package Descriptions

TVM9150PKG

TVM Series waveform monitor package supporting four picture display with HD/SD-SDI
inputs

TVM9150PKG-3GB

TVM Series waveform monitor package supporting four picture display with 3Gb/HD/SD-SDI
inputs

TVM9150PKG-EH

TVM Series waveform monitor package supporting four picture display with HD/SD-SDI eye
pattern inputs

TVM9150PKG-EJ

TVM Series waveform monitor package supporting four picture display with HD/SD-SDI
advanced jitter eye pattern inputs

TVM9150PKG-ES

TVM Series waveform monitor package supporting four picture display with SD-SDI eye
pattern inputs

TVM9150PKG-SD

TVM Series waveform monitor package supporting four picture display with SD-SDI inputs



Video Options

TVM-VTM-SDI-H

2 passive looping SMPTE 292M (HD-SDI) and SMPTE 259M-C (SD-SDI) inputs, auto detect
and monitor output

TVM-VTM-3GB

2 active looping SMPTE 424M (3 Gb/s), SMPTE 372 (dual line), SMPTE 292M (HD-SDI) and
SMPTE 259M-C (SD-SDI) inputs, auto detect and monitor output

TVM-VTM-EYE-H

2 active looping SMPTE 292M (HD-SDI) and SMPTE 259M-C (SD-SDI) inputs, auto detect
with eye pattern and monitor output

TVM-VTM-JEM

2 active looping SMPTE 292M (HD-SDI) and SMPTE 259M-C (SD-SDI), auto-sensing inputs.
Eye pattern display and jitter waveform or spectrum can be viewed individually or together as
part of a quad display

TVM-VTM-SDI-S

2 passive looping SMPTE 259M-C (SD-SDI) inputs, auto detect and monitor output

TVM-VTM-EYE-S

2 active looping SMPTE 259M-C (SD-SDI) inputs, auto detect with eye pattern and monitor
output

TVM-VTM-ACV-2

2 passive looping analog composite video inputs for NTSC or PAL format, auto detect

TVM-VTM-ASI

Dual DVB-ASI/SMPTE 310 input module with MPEG data analysis. Provides single transport
stream program information and bandwidth measurements. Monitors MPEG and ATSC tables
for errors and repetition rates. Alarms for ETSI TR-101-290 first, second and third priority
errors

TVM-VTM-DLK

Expands the dual-link capability of the TVM-VTM-SDI-H, TVM-VTM-EYE-H and
TVM-VTM-JEM to include 10-bit RGB (4:4:4) and RGB+A (4:4:4:4) formats

TVM-VTM-3D

Advanced 3D analysis package that adds 3D picture and waveform displays in quadrant or
full-screen views to the TVM9150PKG and VTM4150PKG

7903.*0XOWLIRUPDW*+'6'9LGHR:DYHIRUP0RQLWRUDQG$XGLR6LJQDO$QDO\]HU
