Eye (Optional)
Sweep Time Base Overlay (3 eye) or 20 eye (HD), 10 eye (SD)
Filters 10 Hz, 100 Hz, 1 kHz
Display Accuracy ±1%
Measurement Analog Bandwidth 250 kHz to 2250 MHz, -3 to 1 dB relative to 750 MHz
Jitter Overshoot ≤20% for all frequencies up to 300 kHz
Intrinsic Jitter <70 ps for HD
<150 ps for SD
Intrinsic Wander <150 ps for HD
<300 ps for SD
Jitter Bar graph showing jitter magnitude
Display Range 0 UI to 1.0 UI
Vector R - Y vs. B - Y for Analog
C
B
vs. C
R
for HD or SD
Vector Accuracy ≤1°
Gamut Encoded or RGB gamut displays with upper and lower limit selection
Audio (Optional) 2, 4, 6 or 8 channels displayed simultaneously
Power Requirements
Power Input 90 to 260 VAC, 50/60 Hz
Power Consumption 180 VA
Dimensions (H x W x D) 5.25 x 8.2 x 16.6 in. (13.34 x 21.6 x 42.24 cm)
Environmental
Operating Temperature 32° to 113° F (0° to 45° C)
Storage Temperature -40° to 149° F (-40° to 65° C)
Humidity 85% maximum (non-condensing)
Operating Altitude To 6,562 ft (2,000 m) above sea level
Pollution Degree 2
Standard Accessories
Operator's manual on CD
GPI/LTC breakout terminal board
DVI to VGA adapter
Spyderweb II Software on CD
Power cord*
*North America cord supplied unless optional cord selected
at time of order
