Extended Capacity Operating Specifications
Bucket Type
Edge Type
Bolt-On
Edges
4.60
6.02
4.05
5.30
3220
10'6"
2978
9'9"
1400
4'7"
2857
9'4"
123
4.8"
8996
29'7"
5875
19'4"
14787
48'7"
20204
44,531
21762
47,964
17668
38,940
19203
42,325
215
48,470
26062
57,440
Capacity–Rated(§) m 3
yd 3
Capacity–Struck(§) m 3
yd 3
Width(§) mm
ft/in
DumpClearanceatMaximumLiftand45°Discharge(§) mm
ft/in
ReachatMaximumLiftand45°Discharge(§) mm
ft/in
ReachatLevelLiftArmandBucketLevel(§) mm
ft/in
DiggingDepth(§) mm
ft/in
OverallLength mm
ft/in
OverallHeightwithBucketatMaximumLift mm
ft/in
LoaderClearanceCirclewithBucketatCarryPosition(§) mm
ft/in
StaticTippingLoad,Straight(ISO)* kg
lb
StaticTippingLoad,Straight(RigidTire)* kg
lb
StaticTippingLoad,Articulated(ISO)* kg
lb
StaticTippingLoad,Articulated(RigidTire)* kg
lb
BreakoutForce**(§) kN
lb
OperatingWeight* kg
lb
General Purpose – Pin On
Teeth and Bolt-On Teeth and
Segments Teeth Edges Segments Teeth
4.60 4.40 4.90 4.90 4.70
6.02 5.75 6.41 6.41 6.15
4.05 3.90 4.20 4.20 4.00
5.30 5.10 5.49 5.49 5.23
3271 3271 3220 3271 3271
10'8" 10'8" 10'6" 10'8" 10'8"
2824 2824 2920 2765 2765
9'3" 9'3" 9'6" 9'0" 9'0"
1537 1537 1448 1584 1584
5'0" 5'0" 4'9" 5'2" 5'2"
3062 3062 2933 3138 3138
10'0" 10'0" 9'7" 10'3" 10'3"
123 93 123 123 93
4.8" 3.6" 4.8" 4.8" 3.6"
9221 9221 9072 9297 9297
30'4" 30'4" 29'10" 30'7" 30'7"
5875 5875 6095 6095 6095
19'4" 19'4" 20'0" 20'0" 20'0"
14961 14961 14827 15001 15001
49'1" 49'1" 48'8" 49'3" 49'3"
20021 20388 20052 19867 20098
44,127 44,936 44,194 43,787 44,296
21574 21959 21624 21434 21667
47,549 48,397 47,660 47,241 47,755
17482 17836 17520 17333 17546
38,531 39,312 38,615 38,202 38,672
19015 19384 19071 18881 19094
41,910 42,722 42,032 41,614 42,085
214 228 204 202 215
48,095 51,358 45,923 45,550 48,516
26200 26037 26185 26323 26160
57,744 57,384 57,712 58,016 57,656
*StatictippingloadsandoperatingweightsshownarebasedonamachineconfigurationwithMichelin26.5R25XHA2L3Radialtires,full
fluids,operator,standardcounterweight,coldstart,roadingfenders,ProductLink,open differentialaxles(front/rear),powertrainguard,
secondarysteering,andsoundsuppression.
**Measured102mm(4")behindtipofcuttingedgewithbuckethingepinaspivotpointinaccordancewithSAEJ732C.
***RockbucketspecificationsaregivenonMichelin26.5R25XLDD2L5Radialtires.
(§)SpecificationsandratingsconformtoallapplicablestandardsrecommendedbytheSocietyofAutomotiveEngineers,includingSAE
StandardJ732Cgoverningloaderratings.
(ISO)FullcompliancetoISO14397­1(2007)Sections1thru6,whichrequires2%verificationbetweencalculationsandtesting.
(RigidTire)CompliancetoISO14397­1(2007)Sections1thru5.
