972K Wheel Loader Specifi cations
Operating Specifications
Bucket Type
Edge Type
Bolt-On
Edges
4.60
6.02
3.90
5.10
3220
10'6"
3120
10'2"
1286
4'2"
3014
9'10"
103
4"
9188
30'2"
6162
20'3"
14957
49'1"
18595
40,983
19901
43,862
16235
35,782
17534
38,646
201
45,174
26279
57,918
Capacity–Rated(§) m 3
yd 3
Capacity–Struck(§) m 3
yd 3
Width(§) mm
ft/in
DumpClearanceatMaximumLiftand45°Discharge(§) mm
ft/in
ReachatMaximumLiftand45°Discharge(§) mm
ft/in
ReachatLevelLiftArmandBucketLevel(§) mm
ft/in
DiggingDepth(§) mm
ft/in
OverallLength mm
ft/in
OverallHeightwithBucketatMaximumLift mm
ft/in
LoaderClearanceCirclewithBucketatCarryPosition(§) mm
ft/in
StaticTippingLoad,Straight(ISO)* kg
lb
StaticTippingLoad,Straight(RigidTire)* kg
lb
StaticTippingLoad,Articulated(ISO)* kg
lb
StaticTippingLoad,Articulated(RigidTire)* kg
lb
BreakoutForce**(§) kN
lb
OperatingWeight* kg
lb
Material Handling – Pin On
Teeth and
Segments Teeth
4.60 4.40
6.02 5.75
3.90 3.70
5.10 4.84
3271 3271
10'8" 10'8"
2957 2957
9'8" 9'8"
1413 1413
4'7" 4'7"
3219 3219
10'6" 10'6"
103 73
4" 2.8"
9412 9412
30'11" 30'11"
6162 6162
20'3" 20'3"
15137 15137
49'8" 49'8"
18413 18653
40,582 41,111
19715 19958
43,453 43,988
16051 16274
35,376 35,869
17349 17573
38,237 38,732
199 213
44,865 47,882
26417 26253
58,222 57,862
Rock – Pin On***
Bolt-On Teeth and
Edges Segments Teeth
3.60 3.60 3.40
4.71 4.71 4.45
3.10 3.10 2.90
4.05 4.05 3.79
3252 3252 3252
10'8" 10'8" 10'8"
3336 3248 3248
10'11" 10'7" 10'7"
1420 1528 1528
4'7" 5'0" 5'0"
2964 3104 3104
9'8" 10'2" 10'2"
44 44 4
1.7" 1.7" 0.1"
9127 9272 9272
30'0" 30'6" 30'6"
6042 6042 6042
19'10" 19'10" 19'10"
14978 15061 15061
49'2" 49'5" 49'5"
19302 19235 19616
42,543 42,394 43,234
20641 20572 20963
45,494 45,342 46,202
16872 16804 17167
37,187 37,036 37,837
18203 18134 18504
40,120 39,968 40,783
222 222 231
50,090 49,982 52,114
26934 26985 26760
59,361 59,473 58,977
*StatictippingloadsandoperatingweightsshownarebasedonamachineconfigurationwithMichelin26.5R25XHA2L3Radialtires,full
fluids,operator,standardcounterweight,coldstart,roadingfenders,ProductLink,open differentialaxles(front/rear),powertrainguard,
secondarysteering,andsoundsuppression.
**Measured102mm(4")behindtipofcuttingedgewithbuckethingepinaspivotpointinaccordancewithSAEJ732C.
***RockbucketspecificationsaregivenonMichelin26.5R25XLDD2L5Radialtires.
(§)SpecificationsandratingsconformtoallapplicablestandardsrecommendedbytheSocietyofAutomotiveEngineers,includingSAE
StandardJ732Cgoverningloaderratings.
(ISO)FullcompliancetoISO14397­1(2007)Sections1thru6,whichrequires2%verificationbetweencalculationsandtesting.
(RigidTire)CompliancetoISO14397­1(2007)Sections1thru5.
