Milton CAT 938H - Manual

® ®
Engine
Engine Model Cat ® 6.6 ACERT™
Net Power – SAE J1349 128 kW 172 hp
Net Power – ISO 9249 134 kW 180 hp
• Caterpillar ® engine with ACERT™ Technology –
EPA Tier III, EU Stage III Compliant.
Buckets
Bucket Capacities 2.3 - 3.0 m 3 3.0 - 4.0 yd 3
Weights
Operating Weight 15 059 kg 33,190 lb
• For 2.8 m 3 (3.65 yd 3 ) general purpose bucket with
standard 20.5-R25 tires.
Operating Specifications
Static Tipping Load, Full Turn 10 076 kg 22,207 lb
• For 2.8 m 3 (3.65 yd 3 ) general purpose bucket with
standard 20.5-R25 tires.
938H
Wheel Loader
