Milton CAT 226B Series 3 - Manual

F EATURES :
The Cat ® 226B Series 3 Skid Steer Loader, with its radial lift design,
delivers excellent digging performance with outstanding drawbar power.
The 226B Series 3 features the following:
Ergonomic operator station features easy to use pilot operated joystick
controls for reduced operator fatigue and increased productivity.
High performance power train provides high engine horsepower
and torque, allowing part-throttle operation for lower sound levels
and fuel consumption.
Advanced hydraulic system is designed for maximum power
and reliability.
Optional high flow system provides increased auxiliary hydraulic
performance with 104 L/min (27 gal/min) of flow for applications that
demand increased work tool performance.
Easy routine maintenance helps reduce machine downtime for greater
productivity.
Broad range of performance matched Cat
® Work Tools make the
Cat Skid Steer Loader the most versatile machine on the jobsite.
Engine
Engine Model Cat ® C2.2 T
Gross Power SAE J1995 45.5 kW 61 hp
Net Power SAE 1349/ISO 9249 42 kW 56 hp
Displacement 2.2 L 134 in 3
Stroke 100 mm 3.9 in
Bore 84 mm 3.3 in
Weights*
Operating Weight 2641 kg 5,822 lb
Power Train
Travel Speed (Forward or Reverse) 12.7 km/h 7.9 mph
Hydraulic System
Hydraulic Flow – Standard:
Loader Hydraulic Pressure 23 000 kPa 3,335 psi
Loader Hydraulic Flow 61 L/min 16 gal/min
Hydraulic Power (calculated) 23.2 kW 31.1 hp
Hydraulic Flow – High Flow:
Loader Hydraulic Pressure 23 000 kPa 3,335 psi
Loader Hydraulic Flow 104 L/min 27 gal/min
Hydraulic Power (calculated) 37.7 kW 50.6 hp
* Operating Weight, Operating Specifications and Dimensions all based
on 75 kg (165 lb) operator, all fluids, OROPS, 1524 mm (60 in) dirt bucket,
standard flow auxiliaries, Cat 10x16.5 tires, no optional counterweights
and manual quick coupler (unless otherwise noted).
Operating Specifications*
Rated Operating Capacity 680 kg 1,500 lb
Rated Operating Capacity 726 kg 1,600 lb
with Optional Counterweight
Tipping Load 1360 kg 3,000 lb
Breakout Force, Tilt Cylinder 1852 kg 4,083 lb
Cab
ROPS SAE J1040 MAY94,
ISO 3471:1994
FOPS SAE J/ISO 3449 APR98
Level I, ISO 3449:1992 Level I
FOPS Level II SAE J/ISO 3449 APR98
Level II, ISO 3449:1992
Level II (optional)
Service Refill Capacities
Chain Box, each side 6 L 1.6 gal
Cooling System 10 L 2.6 gal
Engine Crankcase 10 L 2.6 gal
Fuel Tank 58 L 15.4 gal
Hydraulic System 55 L 14.5 gal
Hydraulic Tank 35 L 9.2 gal
Cat ®
226B Series 3
S
KID
S
TEER
L
OADER
Specifications
