Operating Specifications
Bucket Type
Edge Type
Bolt-On
Edges
4.80
6.28
4.10
5.36
3220
10'6"
3130
10'3"
1419
4'7"
3085
10'1"
103
4"
9259
30'5"
6270
20'7"
14991
49'3"
18105
39,903
19423
42,808
15754
34,722
17068
37,619
190
42,897
26695
58,836
Capacity–Rated(§) m 3
yd 3
Capacity–Struck(§) m 3
yd 3
Width(§) mm
ft/in
DumpClearanceatMaximumLiftand45°Discharge(§) mm
ft/in
ReachatMaximumLiftand45°Discharge(§) mm
ft/in
ReachatLevelLiftArmandBucketLevel(§) mm
ft/in
DiggingDepth(§) mm
ft/in
OverallLength mm
ft/in
OverallHeightwithBucketatMaximumLift mm
ft/in
LoaderClearanceCirclewithBucketatCarryPosition(§) mm
ft/in
StaticTippingLoad,Straight(ISO)* kg
lb
StaticTippingLoad,Straight(RigidTire)* kg
lb
StaticTippingLoad,Articulated(ISO)* kg
lb
StaticTippingLoad,Articulated(RigidTire)* kg
lb
BreakoutForce**(§) kN
lb
OperatingWeight* kg
lb
General Purpose – Fusion QC
Teeth and Bolt-On Teeth and
Segments Teeth Edges Segments Teeth
4.80 4.60 5.00 5.00 4.80
6.28 6.02 6.54 6.54 6.28
4.10 3.90 4.30 4.30 4.10
5.36 5.10 5.62 5.62 5.36
3271 3271 3220 3271 3271
10'8" 10'8" 10'6" 10'8" 10'8"
2975 2975 3106 2951 2951
9'9" 9'9" 10'2" 9'8" 9'8"
1555 1555 1440 1576 1576
5'1" 5'1" 4'8" 5'2" 5'2"
3290 3290 3117 3322 3322
10'9" 10'9" 10'2" 10'10" 10'10"
103 73 103 103 73
4" 2.8" 4" 4" 2.8"
9483 9483 9291 9515 9515
31'2" 31'2" 30'6" 31'3" 31'3"
6270 6270 6296 6296 6296
20'7" 20'7" 20'8" 20'8" 20'8"
15174 15174 15009 15193 15193
49'10" 49'10" 49'3" 49'11" 49'11"
17922 18271 17986 17802 18150
39,500 40,270 39,642 39,237 40,003
19236 19602 19306 19119 19483
42,396 43,203 42,552 42,138 42,941
15569 15903 15636 15450 15783
34,314 35,051 34,462 34,052 34,786
16881 17230 16953 16766 17112
37,207 37,975 37,366 36,952 37,716
189 201 186 185 196
42,588 45,348 41,881 41,572 44,224
26833 26670 26786 26924 26761
59,140 58,780 59,036 59,340 58,980
*StatictippingloadsandoperatingweightsshownarebasedonamachineconfigurationwithMichelin26.5R25XHA2L3Radialtires,full
fluids,operator,standardcounterweight,coldstart,roadingfenders,ProductLink,open differentialaxles(front/rear),powertrainguard,
secondarysteering,andsoundsuppression.
**Measured102mm(4")behindtipofcuttingedgewithbuckethingepinaspivotpointinaccordancewithSAEJ732C.
***RockbucketspecificationsaregivenonMichelin26.5R25XLDD2L5Radialtires.
(§)SpecificationsandratingsconformtoallapplicablestandardsrecommendedbytheSocietyofAutomotiveEngineers,includingSAE
StandardJ732Cgoverningloaderratings.
(ISO)FullcompliancetoISO14397­1(2007)Sections1thru6,whichrequires2%verificationbetweencalculationsandtesting.
(RigidTire)CompliancetoISO14397­1(2007)Sections1thru5.
