Engine
Model Cat ® 3054C DIT
Gross Power (Basic) 74 kW 99 hp
Net Power (Basic) 70.4 kW 94.5 hp
• Net Power shown is the power available at the flywheel
when equipped with fan, air cleaner, muffler and alternator.
Weights
Operating Weight 9180 kg 20,240 lb
Operating Specifications
Rated Load Capacity 2948 kg 6,500 lb
Maximum Lift Height 12.8 m 42 ft
Maximum Forward Reach 9.1 m 30 ft
Frame Leveling 10°
Top Travel Speed 30 kph 20.4 mph
Capacity at Max Height 2948 kg 6,500 lb
Capacity at Max Reach 317 kg 700 lb
Turning Radius over Tires 3.7 m 12 ft
Hydraulic System — Implement
Gear Pump Single-section
• Auxiliary Hydraulic Circuit used for all attachments equipped
with cylinders or other hydraulic components. Consists of valves,
controls and hydraulic lines.
Service Refill Capacities
Fuel Tank 144 L 38 gal
Hydraulic System 151.4 L 40 gal
Tires
Standard 13.00 x 24-12 PR
Optional 13.00 x 24 Foam Filled
13.00 x 24 Rock Lug
13.00 x 24 Solid
Transmission Speeds
Forward 4 speed
Reverse 3 speed
Boom Performance
Boom Up 13 Seconds
Boom Down 10 Seconds
Tele In 13 Seconds
Tele Out 14 Seconds
Drawbar Pull (Loaded) 80.07 kN 18,000 lb
Axles
• Trunnion mounted planetary 55 degree steer axles.
• Integral steer cylinder.
• High bias limited slip differential on front axle.
Brakes
• Service Brakes are inboard wet disc brakes on front and rear axles.
• Parking Brakes are spring-applied hydraulic release on front axle.
Light on dash indicates when brake is on.
Instruments
• Volt meter, hourmeter, engine oil pressure gauge, fuel gauge, water
temperature gauge. All gauges protected by clear acrylic cover.
Work Tools
Hydraulic IT Includes Includes
IT Coupler Auxiliary Electrics Auxiliary Electrics
Pallet Forks (2) 1524 mm, (2) 60 in, 2 in x 6 in
51 mm x 152 mm
(2) 1219 mm, (2) 48 in, 2.36 in x 4 in
60 mm x 102 mm
Cubing Forks (2) 1219 mm, (2) 48 in, 2 in x 2 in
51 mm x 51 mm
Standard Tilt 1270 mm 50 in
Carriage
Wide Tilt
1829 mm 72 in
Carriage
Standard Rotate 1270 mm
50 in
Carriage
Wide Rotate
1829 mm 72 in
Carriage
Swing Carriage 100°, 1829 mm, 4028 kg 100°, 72 in, 9,000 lb
Capacity, 2268 kg Swung Capacity, 5,000 lb Swung
Side Shift 1.22 m 48 in
Carriage
Specifications
Cat
®
TL642
Telehandler
