Milton CAT 972K - Manual (Page 19)

Operating Specifications
Bucket Type
Edge Type
Bolt-On
Edges
5.00
6.54
4.30
5.62
3220
10'6"
3137
10'3"
1407
4'7"
3072
10'0"
103
4"
9246
30'4"
6284
20'8"
14989
49'3"
18779
41,390
20115
44,334
16414
36,177
17739
39,097
198
44,634
26325
58,019
Capacity–Rated(§) m 3
yd 3
Capacity–Struck(§) m 3
yd 3
Width(§) mm
ft/in
DumpClearanceatMaximumLiftand45°Discharge(§) mm
ft/in
ReachatMaximumLiftand45°Discharge(§) mm
ft/in
ReachatLevelLiftArmandBucketLevel(§) mm
ft/in
DiggingDepth(§) mm
ft/in
OverallLength mm
ft/in
OverallHeightwithBucketatMaximumLift mm
ft/in
LoaderClearanceCirclewithBucketatCarryPosition(§) mm
ft/in
StaticTippingLoad,Straight(ISO)* kg
lb
StaticTippingLoad,Straight(RigidTire)* kg
lb
StaticTippingLoad,Articulated(ISO)* kg
lb
StaticTippingLoad,Articulated(RigidTire)* kg
lb
BreakoutForce**(§) kN
lb
OperatingWeight* kg
lb
General Purpose – Pin On
Teeth and
Segments Teeth
5.00 4.80
6.54 6.28
4.30 4.10
5.62 5.36
3271 3271
10'8" 10'8"
2982 2982
9'9" 9'9"
1543 1543
5'0" 5'0"
3277 3277
10'9" 10'9"
103 73
4" 2.8"
9470 9470
31'1" 31'1"
6284 6284
20'8" 20'8"
15170 15170
49'10" 49'10"
18595 18832
40,984 41,507
19927 20166
43,919 44,447
16228 16449
35,767 36,254
17551 17772
38,683 39,171
197 210
44,325 47,205
26463 26299
58,323 57,963
General Purpose – Fusion QC
Bolt-On Teeth and
Edges Segments Teeth
4.20 4.20 4.00
5.49 5.49 5.23
3.70 3.70 3.50
4.84 4.84 4.58
3220 3271 3271
10'6" 10'8" 10'8"
3195 3041 3041
10'5" 9'11" 9'11"
1367 1504 1504
4'5" 4'11" 4'11"
3000 3205 3205
9'10" 10'6" 10'6"
103 103 73
4" 4" 2.8"
9175 9398 9398
30'2" 30'10" 30'10"
6036 6036 6036
19'10" 19'10" 19'10"
14944 15126 15126
49'1" 49'8" 49'8"
18260 18079 18430
40,246 39,848 40,621
19563 19379 19746
43,118 42,711 43,520
15906 15723 16058
35,057 34,653 35,393
17205 17020 17369
37,920 37,513 38,282
203 201 215
45,615 45,306 48,375
26600 26738 26574
58,625 58,929 58,569
*StatictippingloadsandoperatingweightsshownarebasedonamachineconfigurationwithMichelin26.5R25XHA2L3Radialtires,full
fluids,operator,standardcounterweight,coldstart,roadingfenders,ProductLink,open differentialaxles(front/rear),powertrainguard,
secondarysteering,andsoundsuppression.
**Measured102mm(4")behindtipofcuttingedgewithbuckethingepinaspivotpointinaccordancewithSAEJ732C.
***RockbucketspecificationsaregivenonMichelin26.5R25XLDD2L5Radialtires.
(§)SpecificationsandratingsconformtoallapplicablestandardsrecommendedbytheSocietyofAutomotiveEngineers,includingSAE
StandardJ732Cgoverningloaderratings.
(ISO)FullcompliancetoISO14397­1(2007)Sections1thru6,whichrequires2%verificationbetweencalculationsandtesting.
(RigidTire)CompliancetoISO14397­1(2007)Sections1thru5.
19
