Operating Specifications
Bucket Type
Edge Type
Bolt-On
Edges
4.20
5.49
3.70
4.84
3220
10'6"
3225
10'6"
1332
4'4"
2955
9'8"
103
4"
9129
30'0"
5937
19'6"
14925
49'0"
18770
41,371
20088
44,274
16396
36,138
17706
39,024
210
47,189
26223
57,795
Capacity–Rated(§) m 3
yd 3
Capacity–Struck(§) m 3
yd 3
Width(§) mm
ft/in
DumpClearanceatMaximumLiftand45°Discharge(§) mm
ft/in
ReachatMaximumLiftand45°Discharge(§) mm
ft/in
ReachatLevelLiftArmandBucketLevel(§) mm
ft/in
DiggingDepth(§) mm
ft/in
OverallLength mm
ft/in
OverallHeightwithBucketatMaximumLift mm
ft/in
LoaderClearanceCirclewithBucketatCarryPosition(§) mm
ft/in
StaticTippingLoad,Straight(ISO)* kg
lb
StaticTippingLoad,Straight(RigidTire)* kg
lb
StaticTippingLoad,Articulated(ISO)* kg
lb
StaticTippingLoad,Articulated(RigidTire)* kg
lb
BreakoutForce**(§) kN
lb
OperatingWeight* kg
lb
General Purpose – Pin On
Teeth and Bolt-On Teeth and
Segments Teeth Edges Segments Teeth
4.20 4.00 4.40 4.40 4.20
5.49 5.23 5.75 5.75 5.49
3.70 3.50 3.80 3.80 3.60
4.84 4.58 4.97 4.97 4.71
3271 3271 3220 3271 3271
10'8" 10'8" 10'6" 10'8" 10'8"
3071 3071 3229 3076 3076
10'0" 10'0" 10'7" 10'1" 10'1"
1470 1470 1327 1465 1465
4'9" 4'9" 4'4" 4'9" 4'9"
3160 3160 2948 3153 3153
10'4" 10'4" 9'8" 10'4" 10'4"
103 73 103 103 73
4" 2.8" 4" 4" 2.8"
9353 9353 9122 9346 9346
30'9" 30'9" 30'0" 30'8" 30'8"
5937 5937 6230 6230 6230
19'6" 19'6" 20'6" 20'6" 20'6"
15104 15104 14921 15100 15100
49'7" 49'7" 49'0" 49'7" 49'7"
18589 18840 18817 18636 18885
40,971 41,523 41,474 41,074 41,622
19903 20157 20147 19962 20215
43,866 44,427 44,405 43,996 44,554
16213 16447 16437 16253 16485
35,734 36,251 36,227 35,822 36,334
17521 17757 17758 17573 17807
38,616 39,138 39,140 38,731 39,248
208 223 211 209 224
46,880 50,138 47,419 47,109 50,397
26361 26198 26229 26367 26203
58,099 57,740 57,807 58,111 57,752
*StatictippingloadsandoperatingweightsshownarebasedonamachineconfigurationwithMichelin26.5R25XHA2L3Radialtires,full
fluids,operator,standardcounterweight,coldstart,roadingfenders,ProductLink,open differentialaxles(front/rear),powertrainguard,
secondarysteering,andsoundsuppression.
**Measured102mm(4")behindtipofcuttingedgewithbuckethingepinaspivotpointinaccordancewithSAEJ732C.
***RockbucketspecificationsaregivenonMichelin26.5R25XLDD2L5Radialtires.
(§)SpecificationsandratingsconformtoallapplicablestandardsrecommendedbytheSocietyofAutomotiveEngineers,includingSAE
StandardJ732Cgoverningloaderratings.
(ISO)FullcompliancetoISO14397­1(2007)Sections1thru6,whichrequires2%verificationbetweencalculationsandtesting.
(RigidTire)CompliancetoISO14397­1(2007)Sections1thru5.
