Milton CAT 972K - Manual (Page 23)

Operating Specifications
Bucket Type
Edge Type
Bolt-On
Edges
4.00
5.23
3.50
4.58
3252
10'8"
3233
10'7"
1463
4'9"
3073
10'1"
44
1.7"
9236
30'4"
6159
20'3"
15039
49'5"
19183
42,281
20544
45,281
16744
36,905
18098
39,889
204
45,999
27081
59,685
Capacity–Rated(§) m 3
yd 3
Capacity–Struck(§) m 3
yd 3
Width(§) mm
ft/in
DumpClearanceatMaximumLiftand45°Discharge(§) mm
ft/in
ReachatMaximumLiftand45°Discharge(§) mm
ft/in
ReachatLevelLiftArmandBucketLevel(§) mm
ft/in
DiggingDepth(§) mm
ft/in
OverallLength mm
ft/in
OverallHeightwithBucketatMaximumLift mm
ft/in
LoaderClearanceCirclewithBucketatCarryPosition(§) mm
ft/in
StaticTippingLoad,Straight(ISO)* kg
lb
StaticTippingLoad,Straight(RigidTire)* kg
lb
StaticTippingLoad,Articulated(ISO)* kg
lb
StaticTippingLoad,Articulated(RigidTire)* kg
lb
BreakoutForce**(§) kN
lb
OperatingWeight* kg
lb
Rock – Pin On***
Teeth and
Segments Teeth
4.00 3.80
5.23 4.97
3.50 3.30
4.58 4.32
3252 3252
10'8" 10'8"
3142 3142
10'3" 10'3"
1571 1571
5'1" 5'1"
3214 3214
10'6" 10'6"
44 44
1.7" 1.7"
9380 9380
30'10" 30'10"
6159 6159
20'3" 20'3"
15123 15123
49'8" 49'8"
19114 19459
42,128 42,887
20474 20829
45,125 45,907
16674 17016
36,750 37,503
18027 18376
39,733 40,501
204 212
45,886 47,764
27132 26907
59,797 59,301
Rock – Fusion QC***
Bolt-On Teeth and
Edges Segments Teeth
3.60 3.60 3.40
4.71 4.71 4.45
3.10 3.10 2.90
4.05 4.05 3.79
3252 3252 3252
10'8" 10'8" 10'8"
3310 3222 3222
10'10" 10'6" 10'6"
1455 1563 1563
4'9" 5'1" 5'1"
3008 3147 3147
9'10" 10'3" 10'3"
44 44 4
1.7" 1.7" 0.1"
9171 9315 9315
30'2" 30'7" 30'7"
6060 6060 6060
19'11" 19'11" 19'11"
14996 15081 15081
49'3" 49'6" 49'6"
18779 18710 19158
41,390 41,238 42,225
20105 20035 20500
44,312 44,157 45,184
16368 16299 16730
36,076 35,923 36,873
17690 17620 18065
38,990 38,835 39,816
215 214 223
48,357 48,247 50,268
27326 27378 27153
60,225 60,339 59,844
*StatictippingloadsandoperatingweightsshownarebasedonamachineconfigurationwithMichelin26.5R25XHA2L3Radialtires,full
fluids,operator,standardcounterweight,coldstart,roadingfenders,ProductLink,open differentialaxles(front/rear),powertrainguard,
secondarysteering,andsoundsuppression.
**Measured102mm(4")behindtipofcuttingedgewithbuckethingepinaspivotpointinaccordancewithSAEJ732C.
***RockbucketspecificationsaregivenonMichelin26.5R25XLDD2L5Radialtires.
(§)SpecificationsandratingsconformtoallapplicablestandardsrecommendedbytheSocietyofAutomotiveEngineers,includingSAE
StandardJ732Cgoverningloaderratings.
(ISO)FullcompliancetoISO14397­1(2007)Sections1thru6,whichrequires2%verificationbetweencalculationsandtesting.
(RigidTire)CompliancetoISO14397­1(2007)Sections1thru5.
23
